    LineCam12

    The LineCam12 is a digital linescan camera for imaging in the SWIR and visible bands (0.4-1.7 μm).  It has two digital output formats USB3 Vision and Camera Link™ . The device can even be powered by USB3 in most applications.  The LineCam12 utilizes a 1024x1 state of the art InGaAs linear array imager on 12.5 μm pitch that was built for both machine vision and spectroscopy.

    LineCAM12-12.5-1.7-T  (Spectroscopy applications)

    LineCAM12-12.5-1.7-M (Machine Vision applications)

    The LineCam12 also is available in an OEM version stripped of its housing.  This camera can be customized to fit in various user systems.  We can also add custom filters to the array.





    Vision System Design 2017 Innovators Program-

    Gold Level Winner



    Description

    The LineCAM12 is an advanced linescan camera with 14-bit digital data at 37klines/s on USB3 or Camera Link™ outputs.  The camera currently comes in two varieties: 250 μm tall pixels for spectroscopy and 12.5 μm square pixels for machine vision applications.  The camera has incredible versatility enabling full wells from 75ke- to 100Me- with 128 steps of variation as well as integration times from 10 μs to 150s.  On chip optical pixel binning (where every other detector is disconnected from the ROIC thus signal is captured by neighboring pixels) is available by command to trade spectral resolution for increased signal level.  Pixel skipping or binning is also available allowing for 48k lines/s at 512 resolution in the same camera platform, activated by a simple command structure.  The TEC stabilized camera has 31 non-uniformity correction (NUC) tables with 15 factory set and 16 user defined tables to enable flexibility for the given environment.

    This lattice matched InGaAs array is backside illuminated enabling detection from 0.4 to 1.7 μm with no bond pads or wires in the way of your signal and minimize stray reflections found in front side illuminated arrays with many wire bonds near the active imaging area.  The array can be customized to allow optical filters to be placed on the active detector area something that is nearly impossible in front side illuminated devices.  We show this device working with Metaphase's light sources,

    Applications & Features

    LineCam Applications

    • Spectroscopy
    • Machine Vision

    LineCam Features

    • 1024x1 resolution
    • Small 12.5 µm pitch
    • USB3.0 & Camera Link Outputs
    • 250 µm or 12.5 µm tall pixel
    • <75e- read noise
    • 75ke- to 100Me- full well
    • 10us-150s integration time
    • 31 NUC tables (16 user defined)
    • F-, C-, and M42 lens mounts
    • 14 bit A/D >6000:1 dynamic range
    • Trigger control
    • Response from 0.4-1.7 µm  (Backside Illuminated)

    Data Sheet

    Downloadable Data Sheet



    QE Curve

    Linecamqecurve

    Export

    These commodities, technology are subject to the Export Administration Act as declared by the Export Administration Regulations. Diversion contrary to U.S. law is prohibited.

    LineCam12-12.5-1.7T is EAR 99

    LineCam12-12.5-1.7M is 6A003.b.4.a (Department of Commerce License is needed)
